Diam. Mayor

Paso

Diam. Efectivo o Paso

Tornillo

Tuerca

Diam. Menor Centro

Area del Centr Sq. Mn.

Diam.

Mayor

Diam.

Menor



1



0.2



0.870



0.72



0.41



1.02



0.74

1.2

0.2

 1.070 0.92 0.66 1.22 0.94

1.4

0.2

 1.270 1.12 0.98 1.42 1.14

1.7

0.2

 1.570 1.42 1.58 1.72 1.44

2

0.25

 1.838 1.65 2.13 2.03 1.68
2.3

0.25

 2.138 1.95 2.98 2.33 1.98

2.6

0.35

 2.373 2.11 3.49 2.64 2.15

3

0.35

 2.773 2.51 4.94 3.04 2.55

3.5

0.35

 3.273 3.01 7.10 3.54 3.05

4

 0.5 3.675 3.30 8.53 4.05 3.35

4.5

 0.5 4.175 3.80 11.32 4.55 3.85

5

 0.5 4.675 4.30 14.50 5.05 4.35

6

 0.75 5.513 4.94 19.20 6.08 5.03

7

 0.75 6.513 5.94 27.75 7.08 6.03

8

1

 7.350 6.59 34.14 8.11 6.70

9

 1 8.350 7.59 45.28 9.11 7.70

10

 1 9.350 8.59 57.99 10.11 8.70

12

 1.5 11.026 9.89 76.81 12.16 10.05

14

 1.5 13.026 11.89 111 14.16 12.05

16

 1.5 15.026 13.89 152 16.16 14.05

18

 1.5 17.026 15.89 198 18.16 16.05

20

 1.5 19.026 17.89 251 20.16 18.05

22

 1.5 21.026 19.89 311 22.16 20.05

24

 2 22.701 21.19 353 24.22 21.40

27

 2 25.701 24.19 459 27.22 24.40

30

 2 28.701 27.19 580 30.22 27.40

33

 2 31.701 30.19 716 33.22 30.40

36

3

 34.051 31.78 793 36.32 32.10
39 3 37.051 34.78 950 39.32 35.10
42 3 40.051 37.78 1121 42.32 38.10
45 3 43.051 40.78 1306 45.32 41.10
48 3 46.051 43.78 1505 48.32 44.10
52 3 50.051 47.78 1793 52.32 48.10
56 4 53.402 50.37 1993 56.43 50.80
60 4 57.402 54.37 2322 60.43 54.80
64 4 61.402 58.37 2676 64.43 58.80
72 4 69.402 66.37 3460 72.43 66.80
80 4 77.402 74.37 4344 80.43 74.80
Da click sobre la imagen

Si tienes alguna necesidad específica, no dudes, Consultanos.
